Petronas Approved Flanges
McNeil Steel & Alloys FZE, based in the United Arab Emirates, specializes in manufacturing and exporting instrumentation pipe fittings and valves. Their product range includes tubes, pipes, pipe fittings, flanges, instrumentation tube fittings, instrumentation valves, and hardware. They are approved suppliers for major companies such as Total Energies, Shell, ONGC, GASCO, Exxon Mobil, EIL, Chevron Corp, Baker Hughes, and Bahrain Petroleum.
The company is committed to delivering high-quality products and services that meet or exceed customer expectations. Their quality policy emphasizes continuous improvement, adherence to international standards, and maintaining a skilled workforce to ensure product reliability and customer satisfaction.
McNeil Steel & Alloys FZE serves a diverse range of industries, including oil and gas, petrochemicals, power generation, and more. Their extensive product line and industry approvals enable them to meet the specific requirements of these sectors, providing reliable solutions for various applications.
Petronas Approved Flanges: A Benchmark of Quality and Performance
Flanges play a crucial role in industrial piping systems, ensuring reliable connections for transporting fluids and gases. In sectors such as oil and gas, petrochemicals, and energy production, the quality of these components directly impacts operational efficiency and safety. Petronas, a global leader in oil and gas exploration and processing, demands the highest standards for the equipment used in its facilities. Petronas-approved flanges represent this commitment to quality, making them indispensable for critical applications.
This article explores the significance of Petronas-approved flanges, their characteristics, applications, and the role of trusted manufacturers like Mcneil Steel & Alloys FZE, a leading Stainless Steel Flanges Manufacturer known for producing top-tier industrial components.
Features of Petronas Approved Flanges
The specific characteristics of Petronas-approved flanges make them a preferred choice for industries requiring superior performance.
- High Durability: These flanges are constructed from premium-grade stainless steel, ensuring long-lasting performance even in corrosive environments.
- Precision Engineering: Designed with exacting tolerances, they provide a secure fit and reliable operation.
- Resistance to Pressure and Temperature: Built to handle extreme conditions, these flanges can withstand high-pressure systems and fluctuating temperatures.
- Compliance with International Standards: Petronas-approved flanges adhere to globally recognized benchmarks such as ASME, ASTM, and API standards.
As a prominent Stainless Steel Flanges Exporter, Mcneil Steel & Alloys FZE ensures that these features are integral to every flange they deliver.
Applications of Petronas Approved Flanges
The versatility and robustness of Petronas-approved flanges make them ideal for a wide range of industrial applications:
- Oil and Gas Pipelines: Essential for connecting segments of pipelines, ensuring seamless transportation of crude oil and natural gas.
- Offshore Platforms: Used in high-pressure systems, where durability and resistance to seawater corrosion are critical.
- Petrochemical Facilities: Integral in transporting aggressive chemicals within production plants.
- Refining Operations: Provide secure connections in equipment handling high-temperature and high-pressure processes.
- LNG Plants: Ensure reliable connections in systems used for liquefying and transporting natural gas.
Industries rely on the expertise of leading Stainless Steel Flanges Manufacturers to source flanges that deliver consistent performance in these demanding environments.
Get In Touch
| Name | Mcneil Steel & Alloys FZE |
| Address | SAIF-Zone, P.O. Box. 120345, Sharjah, UAE |
| Phone | +91 987 088 3613 |
| info@mcneilalloys.ae | |
| Website | https://mcneilalloys.ae |
Petronas-approved flanges represent the pinnacle of quality and reliability in the industrial sector. Their exceptional durability, precision engineering, and resistance to extreme conditions make them indispensable for applications in the oil and gas, petrochemical, and energy industries.
By partnering with Mcneil Steel & Alloys FZE, industries gain access to superior flanges that meet the rigorous standards of Petronas. As a leading Stainless Steel Flanges Manufacturer and supplier, Mcneil Steel & Alloys FZE combines innovation, quality, and sustainability to deliver products that exceed customer expectations.
Investing in Petronas-approved flanges ensures operational efficiency, safety, and long-term reliability, making them a critical component in industrial systems worldwide.
Petronas approved flanges, stainless steel flanges manufacturer, stainless steel flanges exporter, stainless steel flanges supplier, McNeil Steel & Alloys FZE, high-quality flanges, oil and gas flanges, Petronas standards.
Types of Flanges
| Weld Neck Flange | Blind Flange | Threaded Flange | Slip On Flange |
| Socket Weld Flange | Lap Joint Flange | Orifice Flanges | Reducing Flange |
| Expanding Flange | Specialty Flanges | Swivel Flange | Flange Assembly |
| Nipo Flange | Square Flange | Flange Face | Flange Hub |
| Forged Flanges | Groove and Tongue Flanges | Loose Flange | Spectacle Flanges |
| Flat Flanges | Anchor Flange | Threaded | Cast Flange |
Specifications Of SS 304 Flanges
| Specification | Details |
|---|---|
| Specification | Stainless Steel 304 Flanges |
| Supporting Flange Material | Flange Bolts, Ring Joint, Gasket |
| Design For Size | JIS Flanges, ANSI Flanges, BS Flanges, EN Flanges, ASA Flanges, ASME Flanges, DIN Flanges, PN Flanges |
| Common Types of SS Flange | Flanges 150 LB WNRF, 600# BLRF, Class 300 RTJ, Class 900 SORF |
| Size Chart | 1/2″ (15 NB) To 48″ (1200 NB) |
| Production Process | Forged, Heat Treated, and Machined |
| Coating Flange Faces | Zinc Plated, Yellow Transparent, Oil Black Paint, Anti-rust Paint, Cold and Hot Dip Galvanized |
| Application | Chemical Industry, Water Pipeline Industry, Nuclear Power Plant, Fabrication Industry, Natural Gas Industry, Oil And Gas Industry |
| Standards | JIS Flanges, ISO Flanges, GOST Flanges, UNI Flanges, AWWA Flanges, MSS SP44 Flanges, ASME B16.5 Flanges, ASME B16.38 Flanges, EN-1092 Flanges, BS10 Flanges, DIN Flanges, PN Flanges, ASME B16.47 (Series A, Series B) Flanges |
| Pressure Rating Table | Class 150 LBS, Class 300 LBS, Class 600 LBS, Class 900 LBS, Class 1500 LBS, Class 2500 LBS |
| Connect Type | RF, FF, RTJ, LMF, SMF, LJF |
| Flange Machining Equipment | Sand-blasting machine, Press machine, Bending machine, Pushing Machine, Electric bevelling machine |
SA 182 Gr F304 Chemical Composition and AISI 304 Flanges Mechanical Properties
| Gr. | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
|---|---|---|---|---|---|---|---|---|---|---|
| ASTM A182 F304 | Minimum | – | – | – | – | – | 18.0 | – | 8.0 | – |
| Maximum | 0.08 | 2.0 | 0.75 | 0.045 | 0.030 | 20.0 | – | 10.5 | 0.10 |
| Gr. | Tensile Strength (MPa) Minimum | Yield Strength 0.2% Proof (MPa) Minimum | Elongation (% in 50mm) Minimum | Hardness Rockwell B (HR B) Max | Brinell (HB) Max |
|---|---|---|---|---|---|
| Stainless Steel 304 Flanges | 515 | 205 | 40 | 92 | 201 |
Chemical Properties of 316L Stainless Steel Flanges
| Property | Grade SS 310 | Grade SS 310S |
|---|---|---|
| C | 0.035 max | 0.08 max |
| Mn | 2 max | 2 max |
| Si | 1.0 max | 1.0 max |
| P | 0.045 max | 0.045 max |
| S | 0.030 max | 0.030 max |
| Cr | 16.00 – 18.00 | 16.00 – 18.00 |
| Mo | 2.00 – 3.00 | 2.00 – 3.00 |
| Ni | 10.00 – 14.00 | 11 – 14 |
| Fe | 68.89 min | 67.845 min |
Stainless Steel 316 / 316L Flanges Mechanical & Physical Properties
| Property | Value (SS 316) | Value (SS 316L) |
|---|---|---|
| Density | 8.0 g/cm³ | 8.0 g/cm³ |
| Melting Point | 1400 °C (2550 °F) | 1399 °C (2550 °F) |
| Tensile Strength | Psi – 75000, MPa – 515 | Psi – 75000, MPa – 515 |
| Yield Strength (0.2% Offset) | Psi – 30000, MPa – 205 | Psi – 30000, MPa – 205 |
| Elongation | 35% | 35% |
Stainless Steel 316/316L Flange Equivalent Grades
| Standard | SS 316 | SS 316L |
|---|---|---|
| UNS | S31600 | S31603 |
| WERKSTOFF NR. | 1.4401 / 1.4436 | 1.4404 / 1.4435 |
| AFNOR | Z7CND17‐11‐02 | Z3CND17‐11‐02 / Z3CND18‐14‐03 |
| JIS | SUS 316 | SUS 316L |
| GOST | – | 03Ch17N14M3 / 03Ch17N14M2 |
| BS | 316S31 / 316S33 | 316S11 / 316S13 |
| EN | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 |
Chemical Composition of Nickel-Alloy Flanges
| Superalloy Grade | UNS Equivalent | C | Mn | S | Si | Cr | Ni | Mo | Cu | Ti | Fe |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Nickel 200 | N02200 | 0.08 | 0.18 | 0.005 | 0.18 | … | 99.5(a) | … | 0.13 | … | 0.2 |
| Nickel 201 | N02201 | 0.01 | 0.18 | 0.005 | 0.18 | … | 99.6(a) | … | 0.13 | … | 0.2 |
| Monel 400 | N04400 | 0.15 | 1 | 0.012 | 0.25 | … | 66.5(a) | … | 31.5 | … | 1.25 |
| Monel K-500 | N05500 | 0.13 | 0.75 | 0.005 | 0.25 | … | 66.5(a) | … | 29.5 | 0.6 | 1 |
| Hastelloy B | N10665 | 0.05 max | 1 | … | 1 | 1 | 61 | 28 | … | … | 5 |
| Hastelloy D | – | 0.12 | 0.9 | … | 9.25 | 1 | 82 | … | 3 | … | 2 |
| Inconel 600 | N06600 | 0.08 | 0.5 | 0.008 | 0.25 | 15.5 | 76.0(a) | … | 0.25 | … | 8 |
| Inconel 800 | N08800 | 0.05 | 0.75 | 0.008 | 0.5 | 21 | 32.5 | … | 0.38 | 0.38 | 46 |
| Hastelloy C-276 | N10276 | 0.01 | 0.5 | 0.02 | 0.03 | 15.5 | 57 | 16 | … | … | 5.5 |
| Inconel 625 | N06025 | 0.05 | 0.25 | 0.008 | 0.25 | 21.5 | 61.0(a) | 9 | … | 0.2 | 2.5 |
| Incoloy 825 | N08825 | 0.03 | 0.5 | 0.015 | 0.25 | 21.5 | 42 | 3 | 2.25 | 0.9 | 30 |
| Hastelloy G | N06030 | 0.03 | 1.5 | 0.02 | 0.5 | 22.25 | 44 | 6.5 | 2 | … | 19.5 |
| 20Cb-3 | N08020 | 0.04 | 1 | 0.02 | 0.5 | 20 | 34 | 2.5 | 3.5 | … | … |
Mechanical Properties of Nickel-Alloy Flanges
| Superalloy Grade | UNS Equivalent | Yield Strength (in ksi) | Tensile Strength (in ksi) | Elongation % | Rockwell | Brinell |
|---|---|---|---|---|---|---|
| Nickel 200 | N02200 | 15 | 55 | 35 | – | 90-120 |
| Nickel 201 | N02201 | 12 | 50 | 35 | – | 90-120 |
| Monel 400 | N04400 | 25 | 70 | 35 | – | 110-149 |
| Monel K-500 | N05500 | 100 | 140 | 17 | – | 265-346 |
| Hastelloy B-2 | N10665 | 51 | 110 | 40 | C22 | – |
| Hastelloy D-205 | – | 49 | 114 | 57 | C30-39 | – |
| Inconel 600 | N06600 | 30 | 80 | 35 | – | 120-170 |
| Inconel 800 | N08800 | 30 | 75 | 30 | – | 120-184 |
| Hastelloy C-276 | N10276 | 60 | 115 | 50 | 184 | – |
| Inconel 625 | N06025 | 39 | 98 | 30 | – | 180 |
| Incoloy 825 | N08825 | 35 | 85 | 30 | – | 120-180 |
| Hastelloy G-30 | N06030 | 51 | 100 | 56 | – | – |
| 20Cb-3 | N08020 | 35 | 80 | 30 | B84-90 | 160 |
Inspection & Testing offered by us
| Inspection & Testing | Details |
|---|---|
| Mechanical Testing & Chemical Analysis | Includes testing and analysis of mechanical properties and chemical composition. |
| Fully equipped laboratory for corrosion testing | Includes chlorite contamination, bath analysis, penetration, and residual stress measurement. |
| Micro Structure Examination / Analysis | Analysis of microstructures of materials. |
| Laboratory Spectrometer & Portable Spectrometer | Used for spectral analysis in laboratory and on-site environments. |
| Positive Material Identification [PMI] Tester | Tool for verifying material composition. |
| Hydro Testing of CS Pipes and SS Straight and U-Tubes | Testing for leaks and strength of pipes and tubes. |
| Air Under Water Testing – Straight Length up to 30 Meters | Testing pipes underwater for integrity. |
| Ferrite Content & Surface Finish | Testing for ferrite content and analyzing surface finish. |
| Fibroscope – Checking the inside of tubes (OD ≥ 4.7 MM) | Inspection of internal conditions of tubes. |
| Surface Roughness Testing | Measurement of surface roughness of materials. |
| Non Destructive Testing | Various methods to test without damaging the material. |
| Eddy Current Testing | Testing for cracks and defects using electromagnetic induction. |
| Ultrasonic Testing with full body thickness measurement | Using sound waves to detect thickness and flaws in materials. |
| Real Time Digital Radiography Testing | Real-time inspection through digital X-ray imaging. |
| Conventional Film Radiography | Traditional X-ray film testing for material integrity. |
